97-04 6-Spd Direct Fit Aluminum Radiator

Rating:
100% of 100
Item #:
RA-171
By:
$839.99
No Retail Discount

This item does not qualify for promotional or retail discounts.

In Stock - Ships today if ordered by 3:00 PM ET
-
+
Related To This Item

For a stock C5 Corvette, the factory radiator does its job very well. But, as soon as modifications come into play cooling needs to be addressed. This radiator is a direct replacement for Corvettes that do not require the added benefit of a built-in engine oil cooler (EOC). Fits all 1997-2004 Corvettes with 6-speed transmissions.

Direct Fit radiators are designed to bolt right in - no ifs, ands or buts. Every Direct Fit radiator is made in the USA and begins life as a double row core furnace brazed for strength and accuracy. Press formed tanks are meticulously TIG welded by real craftsman to ensure leak-free performance and knockout looks. The entire radiator is epoxy free. This design eliminates failures due to cracked plastic end tanks and/or gasket leaks and improves horsepower through better cooling efficiencies. Made in USA.

Are two rows really better than three or four? In the era of copper and brass radiators, more rows meant better cooling due to increased surface area. However, with aluminum radiators, the game has changed. Engineers found that reducing fin height and using wider tubes increased tube-to-fin contact, enhancing performance while cutting weight. The U.S. standard for performance aluminum radiators is 1" wide tubes, while imported radiators often use smaller 16mm tubes. This means a 2-row aluminum radiator with 1" tubes offers better cooling than a 3-row imported design.  When researching, focus on tube width for a clearer picture of efficiency and origin.

Dewitts Direct Fit aluminum radiators are warrantied to be free from defects in materials and workmanship for as long as you own the Corvette in which it was originally installed. This warranty is extended only to the first retail purchaser of any such radiator. Proof of purchase must be provided in the way of a sale receipt from DRI or an authorized dealer. If the radiator is used in any racing application this warranty is considered null and void.

Radiators used without an adequate proportion of premium quality antifreeze coolant and distilled water are not covered by this warranty. DRI radiators require a correct proportion of quality coolant, which contains aluminum corrosion inhibitors in the formula and distilled water. All Corvette cooling systems must include a radiator pressure cap with the proper pressure rating. Distilled water and premium antifreeze must be used with all Corvette aluminum radiators!

Dewitt Item Number 32-1139097M

usaiconThis item is proudly Made in the USA

Installation difficulty: 4

Our technicians have determined that the installation difficulty level of this item is a 4 on a scale of 1-5. Read more about our install ratings here.

Model Years

More Information
SKU RA-171
Generation C5
Model Year 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
Additional Item Information
  • Manufacturer Part Number: 32-1139097M
  • P65 Warning WARNING: Cancer and Reproductive Harm - www.p65warnings.co.gov

Dewitt

Based in Michigan, DeWitts Radiator is the only aftermarket radiator manufacturer in the US which owns an aluminum Nocolok blazing furnace. With a twelve-person crew, DeWitts builds custom and direct fit radiators for 1955-present Corvettes from start to finish at their Howell, MI plant. No epoxy is used in the making of their radiators, and their construction methods eliminate seams and possible leak points. Their Lifetime Warranty is industry leading, and Zip only recommends DeWitts Radiators to our customers.
